The jig also makes the process of cutting safer by preventing the blade from slipping out of the material. The plate holds the saw in place against the flat edge of the clamp as the cut is made, ensuring a straight and precise cut. These plates attach the fence on the saw or router to the clamp via the clamp’s T-slot. Some clamps include saw plates, which make using straight edge clamps with a circular saw, router, or jigsaw easier and more precise. Straight edge clamps feature clamping mechanisms with large levers that allow the user to easily tighten the clamp into place on a large piece of material. Most straight edge clamps are designed with ease of use in mind.
It’s crucial for a straight edge clamp to have a strong clamping mechanism with a rubberized clamping head that creates a firm grip on the material for a swivel head to work properly. Most swivel heads operate at a range of 0 to 22.5 degrees. Many straight edge clamps feature a swivel head which allows the clamps to grab the material at an angle to either create a straight fence for miter circular saw cuts or to allow the fence to attach to pieces of wood that don’t have parallel edges. The clamping mechanism should clamp tightly on the material without damaging it and should be able to resist a significant amount of pressure placed against the straight edge. Many straight edge clamps have rubber feet that grip the material, creating a tight connection without causing damage. If the clamping mechanism doesn’t work properly, it will cause the clamp to shift on the material while cutting, throwing off the cut. This end features a lever that forces the clamp face against the piece, locking the clamp firmly onto it. The mechanism features a nonmoving end that presses up against one side of the material and a moving end that slides against the opposite end. The clamping mechanism holds the clamp to the material top to ensure a straight and accurate cut. Clamps with extensions should be wider, ideally 3 inches or more, to prevent bending.
#ACCU RIP SAW GUIDE FULL#
Some edge clamps feature 50-inch extensions that can be added to the clamp for cutting longer pieces of wood, such as a full 4×8 sheet of plywood.
While longer edge clamps allow for making crosscuts on full sheets of plywood, that added length makes them difficult to clamp to smaller pieces of lumber, which are better suited for shorter edge clamps. With this in mind, most edge clamps range between 36 and 50 inches long. To be useful, a straight edge clamp should be long enough to serve as a guide for cutting across wide boards and large pieces of plywood that are too big to run through a table saw. The clamping face should have a rubberized cover capable of gripping the material without leaving indentations that can damage it. To ensure it is strong enough to hold the clamp firmly to the workpiece, the clamping mechanism is typically made from metal and rugged plastic. This length of aluminum is typically 2 to 3 inches wide in order to be strong enough to resist bowing when the pressure of a heavy saw is applied to one side. Straight edge clamps are made from extruded aluminum extruded aluminum is rigid enough to hold a straight edge and durable enough to withstand repeated use. Ahead, learn more about important factors to take into account when shopping for a straight edge clamp. The quality of a straight edge clamp depends on its grip material, length, and the rigidity of its construction. Photo: What to Consider When Choosing the Best Straight Edge Clamp ALSO CONSIDER: DEWALT DWS5100 Dual-Port Folding Rip Guide.BEST FOR CIRCULAR SAW: Kreg Circular Saw Track.
#ACCU RIP SAW GUIDE PROFESSIONAL#
Unlike a standard clamp, which holds workpieces in place, a straight edge clamp provides a guide for cutting. A straight edge clamp is a great solution. While a cut with a few hitches in it may be just fine for rough carpentry, finish work demands greater precision. Making straight cuts with a circular saw, router, or jigsaw is a challenging task.
